LED Flood light-KL-FL-J


IP67 Waterproof Type

Model No. Power Lifespan Luminous Flux Size Protection Class Qty./Carton
KL-LF-J10 10W 50,000Hrs 700 lm 180x185XH40 mm IP67 8
KL-LF-J20 20W 50,000Hrs 1500 lm 180x185XH40 mm IP67 8
KL-LF-J30 30W 50,000Hrs 2200 lm 225x220xH50 mm IP67 8
KL-LF-J50 50W 50,000Hrs 4000 lm 225x220xH50 mm IP67 6
KL-LF-J70 70W 50,000Hrs 5500lm 290x290XH90 mm IP67 4
KL-LF-J100 100W 50,000Hrs 8000 lm 290x290XH90 mm IP67 4
KL-LF-J150 150W 50,000Hrs 12000 lm 350x350XH90 mm IP67 4
KL-LF-J200 200W 50,000Hrs 15500 lm 350x350XH90 mm IP67 4

Applications
Landscaping buildings, Bridges, Squares, Sports Centers, Tunnels, Garden, Subways, undergrounds,
factories, Club, Hotels, Stages, Parks, Parking lots, Plazas and art Galleriesping Mall, Museum,etc

Technical Data:
Operating voltage: 120-277V, 50/60HZ
Lamp: 10W-200W
Housing: High pressure aluminum die-cast body
Thermal resistant clear tempered glass
Power Factor >95%
Lumen Efficency: 90-110lm/w
RA>75

The design ensures a 50, 000 hours life-span for the LED.
The die-casting aluminium alloy housing is effective in waterproofing and dust prevention. It also helps in removing the heat properly.
Compared with traditional sodium lights, it can save electricity more than 70%.

Ambient temperature for lighting fixture:
-35°C~+50°C

Certifications
CE ,RoHS
