LED Tube-T5 Series



Model No.	LED Qty.	Power	Lifespan	Luminous Flux	Size	Qty./Carton
LT-B08	120	8W	40,000Hrs	CW>730lm	578X22X27 mm	50
LT-B12	168	12W	40,000Hrs	CW>1040lm	878X22X27 mm	50
LT-B15	276	15W	40,000Hrs	CW>1450lm	1178X1188.5 mm	50
LT-B25	360	25W	40,000Hrs	CW>2200lm	1478X1488.5 mm	50


Applications
Instead of  the indoors ceiling light,School / Universities / Hospital,Conference / Meeting room , Show Room
Commercial Complexes,Factories / Offices,Super-markets,Residential / Institution buildings Warranty

Product benefits
Very low energy consumption
Extremely long life
Shockproof and vibration-proof thanks to LED technology
No UV and near-IR radiation
No RF interference, Lead free

Technical Data
LED type: SMD 3528
Pin type: T5- G5
CRI : > 75
Materials: Aluminum Base + Transparent PC Cover/ Milk PC Cover
Input Voltage: AC85-265V
luminous efficiency:  80lm/W
Power factor: >95%
Working Frequency: 50-60Hz

Certifications
CE ,RoHS
